E6581595
K-5
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0151 Input terminal
selection 1B (F)
- -
0-201 *7
0 6.3.3
6.5.1
0152 Input terminal
selection 2B (R)
- - 0 7.2.1
0153 Input terminal
selection 3B (S1)
- - 0
0154 Input terminal
selection 4B (S2)
- - 0
0155 Input terminal
selection 1C (F)
- - 0
0156 Input terminal
selection 2C (R)
- - 0
Basic parameter 2
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0170 Base frequency 2 Hz 0.1/0.01 20.0-400.0 * 2 6.4.1
0171 Base frequency
voltage 2
V 1/0.1 50-330 * 2
0172 Torque boost
value 2
% 0.1/0.1 0.0-30.0 * 3
0173 Motor electronic-
thermal protection
level 2
%
(A)
1/1 10-100 100 3.5
6.4.1
6.16.1
0185 Stall prevention
level 2
%
(A)
1/1 10-199,
200 (disabled)
150 6.4.1
6.19.2
Frequency parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0201 VI input point 1
setting
% 1/1 0-100 0 6.5.2
7.3
0202 VI input point 1
frequency
Hz 0.1/0.01 0.0-400.0 0.0
0203 VI input point 2
setting
% 1/1 0-100 100
0204 VI input point 2
frequency
Hz 0.1/0.01 0.0-400.0 * 2
0209 Analog input filter ms 1/1 4-1000
64
0240 Starting frequency Hz 0.1/0.01 0.1-10.0 0.5 6.6.1
0241 Operation starting
frequency
Hz 0.1/0.01 0.0- 0.0 6.6.2
0242 Operation starting
frequency
hysteresis
Hz 0.1/0.01 0.0- 0.0
0249 Factory specific
coefficient 2A
- - - - * 4
*2: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*3: Default setting values vary depending on the capacity. Refer to section 11.4.
*4: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
*7: Refer to section 11.6 for details about input terminal function.
