E6581595
K-7
11
 Operation mode parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference

0300 PWM carrier
frequency
kHz 1/0.1 2 -16 12 6.11

0301 Auto-restart
control selection
- - 0: Disabled
1: At auto-restart after momentary
stop
2: At ST terminal off and on
3: 1+2
4: At start-up
0 6.12.1

0302 Regenerative
power ride-
through control
(Deceleration
stop)
- - 0: Disabled
1: Regenerative power ride-through
control
2: Deceleration stop during power
failure
0 6.12.2

0303 Retry selection
(number of times)
Times 1/1 0: Disabled
1-10
0 6.12.3

0305 Overvoltage limit
operation
(Slowdown stop
mode selection)
- - 0: Enabled
1: Disabled
2: Enabled (Quick deceleration
control)
3: Enabled (Dynamic quick
deceleration control)
2 6.12.4

0307 Supply voltage
correction
(output voltage
limitation)
- - 0: Supply voltage uncorrected,
output voltage limited
* 2 6.12.5
1: Supply voltage corrected,
output voltage limited
2: Supply voltage uncorrected,
output voltage unlimited
3: Supply voltage corrected,
output voltage unlimited

0311 Reverse-run
prohibition
- - 0: Forward/reverse run permitted
1: Reverse run prohibited
2: Forward run prohibited
0 6.12.6

0312 Random mode - - 0: Disabled
1: Automatic setting
0 6.11

0315 Factory specific
coefficient 3A
- - - - * 4

0316 Carrier frequency
control mode
selection
- - 0: Carrier frequency without reduction
1: Carrier frequency with automatic
reduction
1 6.11

0359 PID control
waiting time
s 1/1 0-2400 0 6.13

0360 PID control - - 0: Disabled, 1: Enabled 0

0362 Proportional gain - 0.01/0.01 0.01-100.0 0.30

0363 Integral gain - 0.01/0.01 0.01-100.0 0.20

0366 Differential gain - 0.01/0.01 0.00-2.55 0.00

0380 PID
forward/reverse
characteristics
selection
- - 0: Forward
1: Reverse
0

0391 Hysteresis for
lower-limit
frequency
operation
Hz 0.1/0.01 0.0-ul 0.2 6.8.1
*2: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*4: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
