E6581595
K-12
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0710
Initial panel
display selection
- - 0: Output frequency (Hz/free unit)
1: Output current (%/A)
2: Frequency command value
(Hz/free unit)
3 to 17: -
18: Arbitrary code from communication
19 to 51: -
52: Frequency command value /
output frequency (Hz/free unit)
0 6.18.5
8.2.1
8.3.2
0711
Status monitor 1 - - 0: Output frequency (Hz/free unit)
1: Output current (%/A)
2: Frequency command value
(Hz/free unit)
3: Input voltage (DC detection) (%/V)
4:
Output voltage (command value) (%/V)
5: Input power (kW)
6: Output power (kW)
7: Torque (%)
8: Torque current (%/A)
9 to 11: -
12: Stator frequency (Hz/free unit)
13 to 22: -
23: PID feedback value (Hz/free unit)
24 to 26: -
27: Drive load factor (%)
28 to 51: -
52: Frequency command value /
output frequency (Hz/free unit)
2 8.2.1
8.3.2
0712
Status monitor 2 - - 1
0713
Status monitor 3 - - 3
0714
Status monitor 4 - - 4
0715
Status monitor 5 - - 27
0716
Status monitor 6 - - 0
0719
Selection of
operation
command clear
- - 0: Clear at coast stop and retained at
moff
1: Retained at coast stop and
moff
2: Clear at coast stop and moff
1 6.18.7
0720
Initial extension
panel display
selection
- - 0-52
(Same as f710)
0 6.18.5
8.2.1
8.3.2
0730
Panel frequency
setting prohibition
()
- - 0: Permitted
1: Prohibited
0 6.18.1
0732
Local/remote key
prohibition of
extension panel
- - 0: Permitted
1: Prohibited
1
0733
Panel operation
prohibition
(RUN/STOP keys)
- - 0: Permitted
1: Prohibited
0
0734
Panel emergency
stop operation
prohibition
- - 0: Permitted
1: Prohibited
0
0735
Panel reset
operation
prohibition
- - 0: Permitted
1: Prohibited
0
0736
/
change prohibition
during operation
- - 0: Permitted
1: Prohibited
1
0738
Password setting
()
- - 0: Password unset
1-9998
9999: Password set
0
0739
Password
verification
- - 0: Password unset
1-9998
9999: Password set
0
