Output parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0669 Logic output/pulse
train output
selection (OUT)
- - 0: Logic output
1: Pulse train output
0 6.17.1
0676 Pulse train output
function selection
(OUT)
- -
0: Output frequency
1: Output current
2: Frequency command value
3: Input voltage (DC detection)
4: Output voltage (command value)
5 to 11: -
12: Stator frequency
13: VI input value
14: -
15: Fixed output 1 (output current
100% equivalent)
16: Fixed output 2 (output current
50% equivalent)
17: Fixed output 3
(Other than the output current)
18: RS485 Communication data
19 to 22: -
0 6.17.1
0677 Maximum numbers
of pulse train
kpps 0.01/0.01 0.50-1.60 0.80
0678 Factory specific
coefficient 6B
- - - -
* 4
0681 Analog output
signal selection
- - 0: Meter option (0 to 1 mA)
1: Current (0 to 20 mA) output
2: Voltage (0 to 10 V) output
0
6.17.2
0684 Factory specific
coefficient 6C
- - - -
* 4
0691 Inclination
characteristic of
analog output
- - 0: Negative inclination (downward
slope)
1: Positive inclination (upward slope)
1 6.17.2
0692 Analog output bias % 0.1/0.1 -1.0－+100.0 0
0693 Factory specific
coefficient 6D
- - - - * 4
Operation panel parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0700
Parameter write
protection
selection
- - 0: Permitted
1: Prohibited (Panel and extension
panel)
2: Prohibited (1 + RS485
communication)
0 6.18.1
0701
Current/voltage
unit selection
- - 0: %
1: A (ampere)/V (volt)
0 6.18.2
0702
Free unit display
scale
Times 0.01/0.01 0.00: Disabled (display of frequency)
0.01-200.0
0.00 6.18.3
0707
Free step
(1-step rotation of
setting dial)
Hz 0.01/0.01 0.00: Automatic
0.01-
0.00 6.18.4
*4: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
