E6581595
K-20
11
Table of output terminal functions 2
Function
No.
Code Function Action Reference
40 RUN Run/stop ON: While operation frequency is output or DC braking is in
operation ()
OFF: Operation stopped
3.2.1
41 RUNN Inversion of run/stop Inversion of RUN
56 COT Cumulative operation time alarm ON: Cumulative operation time is or more
OFF: The cumulative operation time is less than
6.16.11
57 COTN Inversion of cumulative operation time alarm Inversion of COT
60 FR Forward/reverse run ON: Reverse run
OFF: Forward run
(Operation command state is output while motor operation is
stopped. No command is to OFF.)
3.2.1
61 FRN Inversion of forward/reverse run Inversion of FR
78 COME RS485 communication error ON: Communication error occurred
OFF: Communication works
6.19
79 COMEN Inversion of RS485 communication error Inversion of COME
92 DATA Designated data output ON: bit0 of FA50 is ON
OFF: bit0 of FA50 is OFF
6.19
93 DATAN Inversion of designated data output Inversion of DATA
128 LTA Parts replacement alarm ON: Any one of cooling fan, control board capacitor, or main
circuit capacitor reaches parts replacement time
OFF: Any one of cooling fan, control board capacitor, or main
circuit capacitor does not reach parts replacement time
6.16.14
129 LTAN Inversion of parts replacement alarm Inversion of LTA
146 FLR Fault signal (output also at a retry waiting) ON: While inverter is tripped or retried
OFF: While inverter is not tripped and not retried
6.12.3
147 FLRN Inversion of fault signal (output also at a
retry waiting)
Inversion of FLR
254 AOFF Always OFF Always OFF 7.2.2
255 AON Always ON Always ON 7.2.2
Note 1: As function No. 12, 13, 18, 19, 30 to 39, 42 to 55, 58, 59, 62 to 77, 80 to 91, 94 to 127, 130 to 145 and 148 to 253
are "No function", output signal is always “OFF” at even number, output signal is always “ON” at odd number.
Note 2:Function No. are different from those on the VF-nC1. Pay attention to substitute function No. from VF-nC1 to VF-nC3.
