TK 61753-2-MM-EN
103
8. Pilot Solenoid 18. Heat Exchanger
9. Condenser Coil 19. Expansion Valve
10. Pulsing Hot Gas Bypass Valve 20. Evaporator Coil
Figure 50. Compressor X430P Components
1. Compressor 17. Discharge Valve
2. Compressor Flange 18. Valve Gasket
3. Compressor Stud 19. Compressor Key
4. HPCO Switch 20. Oil Seal
5. Flare Cap 21. Keyway alignment Tool
6. Valve and cover screw 22. Restriction Fitting
7.
Flatwasher
23.
Discharge Manifold
8. Suction valve 24. Manifold Screw
9. Valve Cap 25. Pipe Plug
RReeffrriiggeerraattiioonn SSeerrvviiccee OOppeerraattiioonnss
