136
TK 61753-2-MM-EN
7. Drain Hose 17. Harness Clip
8. Bracket 18. Housing Gasket
9. Fan (Blower) Housing (Right) 19. Foam Strip straight
10. Fan (Blower) Cover 20. Foam Strip curved
Fan Controller Replacement
Removal
1. Unscrew the 4 screw of the generator terminal box.
2. Unscrew the 3 nuts.
3. Disconnect the 3 generator cables
SSttrruuccttuurraall MMaaiinntteennaannccee
