66
TK 61753-2-MM-EN
4. Install the drain plug.
Fuel Filter/Water Separator
The fuel filter/water separator filters the fuel, and removes water from the fuel and returns it to the fuel tank.
Fuel Filter/Water Separator Replacement
Replace the fuel filter/water separator at intervals according to the Maintenance Inspection Schedule.
1. Unscrew the fuel filter/water separator canister with a strap wrench. Drain, and dispose of properly.
2. Clean the filter head seal surface.
3. Lubricate the canister seal with clean fuel.
4. Through one of the small openings in the top of the canister, fill the new fuel filter/water separator canister with
clean fuel. This will purge the air from the canister. Do not fill canister through the center hole.
Figure 15. Filling Fuel Filter/Water Separator
1. Fill Through Small Openings
2. Do Not Fill Through Center Hole
5. Screw the new canister on hand-tight. Using a strap wrench, tighten another 1/4 turn.
Engine Speed Adjustments
This unit in installed with engine type TK486VMGS5. This is to confirm compliancy with 2016/1628 EU regulation (or
NRMM Stage V). To determine if an engine is NRMM Stage 5 compliant, the engine model shall be stated on the engine
serial plate (located on engine behind trailer service doors). See below an example of engine serial plate.
Figure 16. Engine Serial Plate for NRMM
These units have been certified in the category NRE-v/c-2 which obliges to limit engine capacity to maximum 19kW
(25.48hp). As a result of this legislation this unit needs to be controlled to sub 19kW using the following procedures.
NRMM Speed Calibration
Select CONFIRM to enter the NRMM calibration menu.
EEnnggiinnee MMaaiinntteennaannccee
To Next Page
