TK 61753-2-MM-EN
29
Table 1. 12 Volt Fuses in Harness (continued)
40A Charge Supply
40A Starter Solenoid
20A LPM (Low Power Module)
20A HPM (High Power Module
Please refer to (“Power Distribution Module (PDM),” p. 49) for the PDM fuses, their location and function.
Serial Number Locations
Figure 4. A-Series Serial Number Locations (inside unit) Shown
UUnniitt DDeessccrriippttiioonn
