TK 61753-2-MM-EN
17
Specifications
Engine
Model Thermo King TK486VMGS5 (NRMM Stage V compliant)
Fuel Type Diesel fuel must conform to EN590
Oil Capacity 12.3 liters/litres crankcase and oil filter
Fill to full mark on dipstick
Oil Type Petroleum Multi-grade Oil
Synthetic Multi-grade Oil
API Type CI-4, ACEA Class E3
API Type CI-4, ACEA Class E3 (after first 500 hours)
Oil Viscosity (based on ambient
temperature)
-10 C to 50 C (14 F to 122 F): SAE 15W-40 (Synthetic)
-15 to 40 C (5 to 104 F): SAE 15W-40
-15 to 40 C (5 to 104 F): SAE 10W-30 (Synthetic or
Synthetic Blend)
-25 to 40 C (-13 to 104 F): SAE 10W-40
-25 to 30 C (-13 to 86 F): SAE 10W-30
-30 to 50 C (-22 to 122 F): SAE 5W-40 (Synthetic)
Below -30 C (-22 F): SAE 0W-30 (Synthetic)
Nominal Engine RPM
NNOOTTIICCEE
EEqquuiippmmeenntt DDaammaaggee!!
DDoo NNOOTT ooppeerraattee tthhee eennggiinnee
iinn AANNYY uunniitt mmoorree tthhaann 110000
RRPPMM oovveerr tthhee hhiigghh ssppeeeedd
sseettttiinngg sshhoowwnn ttoo aavvooiidd
ddaammaaggee ttoo tthhee aaccttiivvee
rreeccttiiffiieerr..
A360 1450 RPM High Speed, 1200 RPM Low Speed
Engine Oil Pressure 2.1 to 5.5 bar (30 to 80 psi)
Intake Valve Clearance 0.15 to 0.25 mm
Exhaust Valve Clearance 0.15 to 0.25 mm
Valve Setting Temperature 21°C
Timing Injection Pump 12° +/– 1° BTDC (timed on No. 1 cylinder, flywheel side)
Low Oil Pressure Switch (Normally
Closed)
0.55 to 0.83 bar (8 to 12 psi)
High Coolant Temperature Switch Sensor - 101.7 to 107.2 C or higher (Shutdown)
Engine Coolant Thermostat 71°C
Engine Coolant Type
NNOOTTIICCEE
SSyysstteemm CCoonnttaammiinnaattiioonn!!
DDoo nnoott aadddd ““GGRREEEENN”” oorr ““BBLLUUEE--GGRREEEENN”” ccoonnvveennttiioonnaall
ccoooollaanntt ttoo ccoooolliinngg ssyysstteemmss uussiinngg ““RREEDD”” EExxtteennddeedd LLiiffee
CCoooollaanntt,, eexxcceepptt iinn aann eemmeerrggeennccyy.. IIff ccoonnvveennttiioonnaall ccoooollaanntt iiss
aaddddeedd ttoo EExxtteennddeedd LLiiffee CCoooollaanntt,, tthhee ccoooollaanntt mmuusstt bbee
cchhaannggeedd aafftteerr 22 yyeeaarrss iinnsstteeaadd ooff 55 yyeeaarrss..
ELC (Extended Life Coolant), which is “RED”
Use a 50/50 concentration of any of the following
equivalents:
Texaco ELC (7997, 7998, 16445, 16447)
Havoline Dex-Cool® (7994, 7995)
Havoline XLC for Europe (30379, 33013)
Shell Dexcool® (94040)
Shell Rotella (94041)
Saturn/General Motors Dex-Cool®
Caterpillar ELC
Detroit Diesel POWERCOOL® Plus
Coolant System Capacity 5.3 liters/litres (5.6 quarts)
Radiator Cap Pressure 0.88 bar (12.8 psi)
Drive
Direct to compressor clutch and belt from electric motor/
generator, and belt to water pump.
