Trane Technologies Thermo King Advancer A360 - Condenser Fan Component Description and Locations

TK 61753-2-MM-EN
135
Condenser Fan Component Description and Locations
1.
Fan (Blower) Housing (Left)
11. Fan (Blower) (Counter Clockwise)
2.
Fan (Blower) Cover
12.
Grille
3. Fan (Blower) (Clockwise) 13.
Blockoff Panel (Right)
4. Inlet 14. Bracket
5. Grille 15. Grille Clamp
6. Blockoff Panel (Left) 16. Plug (Plastic)
SSttrruuccttuurraall MMaaiinntteennaannccee
