Electrical Components
Note: Disconnect components from the unit circuit to check resistance.
Component Current Draw (Amperes) at
12.5 Vdc
Resistance (Ohms)
Starter Motor 350 to 475 (cranking)
Air Heater 89 0.14
Fuel Solenoid Pull-in Coil
Hold-in Coil
35 to 45
0.5 or 1.0
0.2 to 0.3
24 to 29
Throttle Solenoid
2.0 4.3
Pilot Solenoid
0.7 17.0
Hot Gas Bypass Valve 1.1 11.1
SSppeecciiffiiccaattiioonnss
