Figure 5. AC Generator
1. Combined standby motor and generator 7. Non Drive End Bracket
2. Generator Key 8. Non Drive End Bearing
3. Drive Bearing 9. Bracket
4. Drive Bracket 10. Clamp
5.
Rectifier
11. Bracket to Engine Screw
6. Fan Cover 12. Bracket to Engine Flatwasher
EElleeccttrriiccaall MMaaiinntteennaannccee
