78
TK 61753-2-MM-EN
Figure 31. Align Flat Sides of Crankshaft Gear with Flat Sides of Inner Rotor in Timing Gear Cover
1.
Crankshaft Gear
2. Oil Pump Cover
3. Outer Rotor
4. Inner Rotor
5. Timing Gear Cover
6. Flat Sides on Inner Rotor
7.
Flat Side on Crankshaft Gear
EEnnggiinnee MMaaiinntteennaannccee
