Description
Technical data
29
Technical data
For the technical data regarding your specific machine, please refer to the
performance specifications of your order confirmation. The following refers to
the general technical data of preference items.
Mechanical data
Name Data
Design variants Nominal length (LF) / nominal width (BN) /
conveying height (HF): Check performance specifi-
cations
Nominal length (LF) 1,000 mm - 3,500 mm for terminal drives
1,400 mm - 15,000 mm for central drives
Nominal width (BN) 500 - 1,500 mm in steps of 100 mm
Conveying height (HF) min. 230 mm, with hanging motor arrangement 500
mm
Drive position right / left
Basic frame Aluminium-bolted construction with bottom
conveyor cover
Belt bed Flat board combination plate
Pulley diameter 100 mm with terminal drive
160 mm for central drives
Conveyor belt type (YG) Two-part belt with woven fabric inlay
Load max. 50 kg
Conveying speed (vF) 2 m/s
Drive power (PN) from 1.1 kW, depending on the speed and loading,
see performance specifications or motor type iden-
tification plate
Type of drive Shaft-mounted worm gear motor
Shaft-mounted bevel gear motor
Spur gear motor
(see contract specifications)
Electrical data
Name Data
Motor voltage supply Standard: 230 V / 400 V AC 50 Hz,
see motor type identification plate for deviations
Motor brake voltage Standard: 230 V AC/400 V AC, see motor type
identification plate for variations
Protection class Standard: IP55, not explosion-protected
