Repair
Tightening torques
56
Operating instructions: Belt conveyor TS 1208
Version 1.6ENG, 10/04/2018
Tightening torques
The tightening torques are based on a medium friction coefficient of
µtot=0.125. They must be followed for screw joints.
For special connections, heed the tightening torques specified in the respec-
tive drawings.
Guards
Fixed guards as defined by the Machinery Directive 2006/42/EC are exclu-
sively for the protection of persons against the hazards arising from moving
parts (Machinery Directive 2006/42/EC: Annex 1 Nos. 1.3.8.1 and 1.3.8.2).
The machinery directive stipulates that these protective devices must be
attached by means of captive fasteners so that they remain attached to the
protective devices or machine when removed.
TRANSNORM provides captive fasteners for protective devices if the oper-
ating company needs to remove a safety device from a machine. This is
necessary for maintenance and cleaning. Generally no hazard is posed by
the loss of captive fasteners when a fixed guard is removed from the
machine by technical personnel to conduct repairs.
TRANSNORM uses fixed guards to provide effective protection in dangerous
areas. Such protective devices may include covers
that are rarely/never removed
that are opened/removed only by technical personnel
that cover a low risk potential only
Tightening torques
Values for screw connections on steel parts Value for screw connections
on aluminium parts
Galvanised screws Black, untreated screws Galvanised screws
Tightening torques [Nm] Tightening torques [Nm] Tightening torques
[Nm]
d 5.6 8.8 10.9 5.6 8.8 10.9 d 5.6 8.8/10.9
M5 2.5 5.4 7 2.8 6 8 M5 2.5 5.4
M6 4.5 9.5 13 4.8 10 14 M6 4.5 9.5
M8 11 23 32 12 25 35 M8 11 23
M10 22 46 64 23 49 69 M10 22 46
M12 38 80 110 40 86 120 M12 28 80
M14 60 125 180 64 135 190 M14 60 125
M16 92 195 275 98 210 295 M16 92 195
