Description
Machine areas
32
Operating instructions: Belt conveyor TS 1208
Version 1.6ENG, 10/04/2018
Machine areas
The conveyor consists of the following areas:
Areas of TS 1208 (central drive design version), example illustration
Explanation of the illustration
No. Name
1 Deflection
2 Support
3 Conveyor track
4 Gear motor
5 Drive station
