Transport and installation
Final place of installation
44
Operating instructions: Belt conveyor TS 1208
Version 1.6ENG, 10/04/2018
3. Only in the case of floor anchorage: Anchor the supports so they can no
longer change position. The foot plates of the supports are equipped with
corresponding bore holes.
4. Only in the case of ceiling suspension: Anchor the suspensions so they
can no longer change position. The lugs of the suspensions are already
equipped with bore holes.
5. Use retaining bolts to secure all joints with positive locking.
6. Manually check the transfer accuracy at the front and back of the
machine. To carry out this check, use loads according to specifications.
The machine has been aligned.
The machine has been installed and aligned.
Fitting side guides
It depends on the scope of delivery whether your conveyor is delivered with
side guides. See the performance specifications for this information.
Carry out the following work steps:
1. Fit the side guides.
2. If necessary, attach photoelectric sensor supports in such a way that it
becomes impossible to reach into the conveyed load flow.
3. If the danger is still present, affix the warning label "Hand injury" to the
side guide next to the dangerous area on the outside. Make sure it is
highly visible.
The side guide has been fitted.
