Transport and installation
Final place of installation
41
Final place of installation
We recommend that installation is carried out by TRANSNORM SYSTEM
GmbH. Alternatively, final installation could be carried out under the supervi
-
sion of or after instruction by TRANSNORM SYSTEM GmbH.
In any case, installation must be carried out by technical personnel author-
ised by the operating company.
Please take into consideration that some work steps in the following
assembly instructions may not apply to your individual conveyor due to varia
-
tions in the design version and equipment.
Installation
Curve belt conveyors are almost always delivered in one piece. Curve belt
conveyors delivered in several parts require installation work by TRANS-
NORM SYSTEM GmbH. Do not install these machines yourself.
Carrying out installation
In the case of long conveyors consisting of several sections, it may be advis-
able to fit supports to the individual sections before assembling the frame.
Depending on the design version, the supports are either equipped with
stand pipes or support angles. Installation is carried out in accordance with
the support layout drawing. The supports must always stand vertically; this
also applies to tracks with an incline.
Mounting supports
Danger of fatal injury through crushing of parts of the body!
The machine falls.
Only use supports/suspensions approved by Transnorm.
Mount the supports/suspensions exactly as described in the system
layout or support layout drawing if available.
Do not exceed minimum clearances as defined in the system
layout/support layout drawing.
Carry out the following work steps:
1. Attach the supports or suspensions to the framework of the base frame
using the joining elements (1) provided.
2. Loosen the mounting bolts (2) and adjust the angle of inclination.
