Transport and installation
In-company transportation
38
Operating instructions: Belt conveyor TS 1208
Version 1.6ENG, 10/04/2018
Auxiliary equipment
Required auxiliary equipment
Overhead crane, gantry crane Carrying capacity 2,000 kg
Industrial truck Carrying capacity 2,000 kg
min. lifting height 4,000 mm
Lift truck cross beam,
carrying capacity 2000 kg
Lift truck hook,
carrying capacity 2000 kg
Adjustable cross beam,
carrying capacity 2,000 kg
L max. = 4,000 mm
L min. = 2,000 mm
Cross beam, adjustable on two
sides
Carrying capacity 2000 kg
La max. = 4000 mm
La min. = 2000 mm
Lb max. = 2000 mm
Lb min. = 1000 mm
Round sling,
carrying capacity 1000 kg
U min = 3 m
