Add L2+IPv4
To add an L2+IPv4 policy, use the following procedure:
• Click Add L2+ IPv4, The Policy Settings page.
• Enter a number in the Policy Index field. The Policy Index is a unique number
within the range of 1 – 65535 which identifies the policy. This field is
mandatory.
• Choose the parameters to add for the policy, and enter data one or more of the
parameters required for your policy. They are listed here:
o Source MAC Address - Specifies the source MAC address. The format
is xx.xx.xx.xx.xx.xx.
o Source MAC Mask Length - Indicates the length of the Source MAC
Mask ranging from 1- 48.
o Destination MAC Address - Specifies the destination MAC address.
The format is xx.xx.xx.xx.xx.xx.
o Destination MAC Mask Length - Indicates the length of the
Destination MAC Mask ranging from 1 - 48.
o VLAN ID - A unique number identifying a VLAN ranging from 1 to
4094.
o 802.1p Priority - 802.1p priority level of the frame ranging from 0 to 7.
o Ether Type - Indicates the protocol of the ethernet frame protocol
ranging from 0000 to FFFF.
o Protocol - Indicates the packet protocol ranging from 0 to 255.
o Source IP Address - Specifies the source IP address.
o Source IP Mask Length - Specifies the mask length of the source IP
address ranging from 0 - 32.
o Destination IP Address - Specifies the destination IP address.
o Destination IP MAC Mask Length - Specifies the mask length of the
destination IP address ranging from 0 - 32.
o DSCP - The DSCP (Differentiated Services Code Point) value in the IP
header ranging from 0 - 63.
o Source Layer 4 Port - Indicates the source layer 4 port ranging from 1 -
65535.
o Destination Layer 4 Port - Indicates the destination layer 4 port
ranging from 1 - 65535.
o Policy Sequence: Enter a number in the Policy Sequence field. The
Policy Sequence must be a unique number within the range of 1 -
65535. This field is mandatory.
o Policy Action: In the Permit/Deny field, use the pull down menu to
select one of the following parameters:
o Deny - This selection drops ingress packets that conform to the
specified Replaced-CoS or Replaced-DSCP.
o Permit - This selection allows ingress packets that conform to the
specified Replaced-CoS or Replaced-DSCP to be processed by the
switch.
Note: You must enter a selection for Deny/Permit field even if the
Profile Action ID that you have entered ignores both the Replaced-
DSCP and Replaced-CoS fields.
o Replaced-CoS: Enter a number in the Replaced-CoS field ranging from
0 to 7. This field indicates the CoS level of interest. This field is not
mandatory and you may elect to leave it blank
o Replaced-DSCP: Enter a number in the Replaced-DSCP field within the
range of 0 to 63. This field indicates the DSCP level of interest. This
field is not mandatory and you may elect to leave it blank.
o Rate Control Index: The Rate Control Index is a unique number within
the range of 1 - 65535. This field is mandatory and must match a Port
List Index that has been previously entered on the Policy Index.
o Port List: Select the interface for which you want to display data.
• Click Add to add the policy to the Policy Table.
