Triumph Adler P-3521 - Part Names (Machine Exterior)

2-2
Installing and Setting up the Machine > Part Names (Machine Exterior)
Part Names (Machine Exterior)
1 Document Processor
2 Inner Tray
3 Paper Stopper
4 Cassette 1
5 Power Switch
6 Front Cover Open Button
7 Original Eject Table
8 Original Stopper
9 Original Table
10 Original Width Guides
11 Slit Glass
12 Operation Panel
13 Platen
14 Original Size Indicator Plates
