Parameter interface, with the minimum value of 0.01.
Table1-6-4 Output Port Instruction
PIN
Name
Instruction
1.OUT
1
OUT1
Blowing signal (blow all the working time):
OUT1 Blowing when output is high logic level.
OUT1 Do not blow when output is low logic level.
2
OUT2
Blowing signal (blow when laser is powering on):
OUT2 Blowing when output is high logic level.
OUT2 Do not blow when output is low logic level.
3
OUT3
Reserved
4
GND
Power ground (OUT).
2.OUT
1
OUT4
Reserved
2
OUT5
Reserved
3
OUT6
Reserved
4
GND
Power ground (OUT).
