Trotec SP3000 - Page 107

www.troteclaser.com
Technical Datasheet
4
3210 mm / 126 in
60 mm / 2.4 in3914 mm / 154 in
3076 mm / 121 in 2210 mm / 87 in
Figure 3: Top view
Operating console exterior dimensions
600 mm / 24 in
500 mm / 20 in 50 mm / 2 in
800 mm / 32 in
700 mm / 28 in
1100 mm / 44 in 1126 mm / 45 in
50 mm / 2 in
600 mm / 24 in
800 mm / 32 in
Figure 1: Side, front & top view
