Trotec SP3000 - Cleaning the protective glass 2,5 inch

Maintenance
9.3.6 Cleaning the protective glass 2,5 inch
1. Take off the magnetically fixed laser deflector shield.
2. Clean the laser deflector shield with a dry or damp
cloth on both sides.
3. Unplug the air assist hose by pressing the blue
clamping ring.
ENGLISH (Translation) 93
