Machine overview
4 Machine overview
4.1 General overview
No Description No Description
1 Emergency stop button 12 X-axis
2 Dust protection belt 13 Reflector
3 Side panel 14 Traveling exhaust
4 Tables 15 Monitor
5 Light sensor 16 Key switch
6 Safety bumper 17 Keyboard
7 Warning lamp 18 Connection cables (mains, exhaust and cooling system)
8 boom for travelling exhaust
(incl. head exhaust tubing )
19 Main switch
9 Laser head 20 Type plate
10 Hall sensor 21 Front and back cover
11 Laser protection disc 22 Operating console
