Technical Data
Technical data of the corresponding exhaust systems:
Exhaust system Hose connection ø [mm]
(inside diameter)
Volume flow [m³/h] Pressure[Pa]
Atmos Duo Plus 70 (2x) 320 8500 (230V)
Vent Set 300 80 max. 1000 max. 2550
Vent Set 400 100 max. 1000 max. 3800
Vent Set 500 100 max. 1200 max. 7000
Vent Set 1500 200 max. 2500 max. 5460
80 max. 600 max. 4360
Vent Set 3000
200 max. 2500 max. 5460
Requirements for the exhaust system:
Machine Volume flow [m³/h] Pressure [Pa]
SP500 400 3900
SP1500 3500 500
min. 2500 (with table exhaust) 800 (with table exhaust)SP2000
min. 100 (traveling exhaust) 4450 (traveling exhaust)
SP3000 max. 1200 max. 7000
SP4000 max. 2500 max. 5460
The monitoring point for flow rate and pressure is at the exhaust port at the laser machine. Pressure loss
by hoses / pipes or filter parts of the exhaust system has to be determined and additionally calculated when
selecting a proper exhaust system.
A powerful exhaust system keeps the lifetime of optics and mechanical components, the cutting quality and
the laser power interacting with the workpiece from being impaired by fumes and dust accumulating in the
machine.
42 ENGLISH (Translation)
