Trox Technik FKR-EU - Mortar-Based Installation into Solid Ceiling Slabs

5.11.2 Mortar-based installation into solid ceiling slabs
Mortar-based installation into a solid ceiling slab, suspended or upright
Fig. 80: Mortar-based installation into a solid ceiling slab, suspended or upright
1 FKR-EU
2.1 Mortar
2.2 Reinforced concrete
4.1 Solid ceiling slab
9.2 Extension piece or duct
Z Spigot construction 370 mm
Flange construction 342 mm
–
Up to EI 120 S
Installation
Solid ceiling slabs > Mortar-based installation into solid ceiling s...
Fire damper FKR-EU106
