Trox Technik FKR-EU - FKR-EU with Fusible Link

2.2 FKR-EU with fusible link
Dimensions and weight
Fig. 2: FKR-EU with fusible link
1 Spigot construction
2 Flange construction
3 Keep clear to provide access for operation
A Installation side
B Operating side
 W
eight of FKR-EU with fusible link, see table Ä 12 .
Limit switch
Connecting cable length / cross section 1 m / 3 × 0.34 mm²
Protection level IP 66
Type of contact 1 changeover contact, gold-plated
Maximum switching current 0.5 A
Maximum switching voltage 30 V DC, 250 V AC
Contact resistance approx. 30 mΩ
Technical data
FKR-EU with fusible link
Fire damper FKR-EU 11
