Minimum number of fixing points in the bare ceiling
B A
≥ 315 ≥ 500 ≥ 800 ≥ 1
100 ≥ 1400 ≥ 1700 ≥ 2000
≥ 315 4 6 8 10 12 14 16
≥ 500 6 8 10 12 14 16 18
≥ 800 8 10 12 14 16 18 20
≥ 1
100 10 12 14 16 18 20 22
≥ 1400 12 14 16 18 20 22 24
≥ 1700 14 16 18 20 22 24 26
≥ 2000 16 18 20 22 24 26 28
Additional requirements: mortar-based installation
into solid ceiling slab with concrete base – multiple
occupancy of an installation opening
Solid ceiling slab,
Ä
on page 36
Total fire damper area (Æ nominal width) ≤ 4.8 m
2
The number of fire dampers in an installation
opening is limited by their damper size
(Æ nominal width) and the overall area of the fire dampers (4.8 m
2
).
The dampers can be arranged in one or two rows.
Structural properties of the ceiling construction,
including the attachment to the mortar/concrete or
any required reinforcement, have to be evaluated
and ensured by others.
Installation
Solid ceiling slabs > Mortar-based installation into the concrete ba...
Fire damper FKR-EU 119
