Installation orientations (see installation details for fire resistance properties)
Supporting construction Installation type
Mortar-based instal-
lation
Dry mortarless
installation
Fire batt installation
Solid wall A – F A, B, D – F
Gypsum wall boards E, F
Lightweight partition walls / compartment
walls with metal support structure
A – F E, F A, B, D – F
Timber stud wall or half-timbered construc-
tion
A – F E, F A, B, D – F
Solid wood wall / cross-laminated timber wall A, B, D – F E, F A, B, D – F
Shaft wall with metal support structure C, E, F
Shaft wall without metal support structure E, F
Solid ceiling slab A – F
Hollow chamber ceiling, hollow stone ceiling,
composite ceiling, ribbed ceiling
E, F
In combination with lightweight ceiling
(Cadolto system)
A, B, D – F
In / in combination with solid wood ceiling E / A, B, D – F E / –
In / in combination with wooden beam ceiling E / A, B, D – F E / –
Historical wooden beam ceilings E
Installation
General installation information
Fire damper FKR-EU30
