1 FKR-EU
2.4 Coated board system
3.2 Lightweight partition wall with metal support
structure, cladding on both sides
3.6 Compartment wall or safety wall with metal sup-
port structure, cladding on both sides
4.1 Solid ceiling slab
6.5 Mineral wool (depending on wall construction)
7.10 Trim panels
7.11 Fire-resistant trim panels, double, in case of
W > 100 mm
7.13 Cladding
7.14 Reinforcing board of the same material as the
wall
Z Spigot construction 370 mm
Flange construction 342 mm
s2 Spigot construction 40 – 600 mm
Flange construction 80 – 600 mm
*
Installation near the floor analogous to
–
Up to EI 60 S
EI 30 S
Installation
Lightweight partition walls > Dry mortarless installation with fire batt
Fire damper FKR-EU68
