2–16
MODE
The Model 2701-B provides three measurement modes:
♦ In continuous mode, the gauge takes a measurement and
updates the display every second. This mode is used for typical
quality control measurements.
♦ In averaging mode, the operator can take up to 30
measurements at selected locations. The gauge then calculates
the average of the measurements. This mode enables the
operator to determine the average density over a selected area.
The Store function (see page 5–10) records the most recent
results screen when in this mode.
♦ In segregation mode, the operator can take up to 30
measurements at selected locations. The gauge then displays the
high, low, and average density of the readings. This mode
enables the operator to determine the degree of segregation in
the area being measured. The Store function (see page 5–10)
records the most recent results screen when in this mode.
Before taking a measurement, select the appropriate measurement
mode. To select a measurement mode, press the 〈MODE〉 key. The
gauge displays:
-MODE-
1. Continuous
2. Averaging
3. Segregation
Press the numeric key that corresponds to the desired measurement
mode. The gauge enables the selected mode, displays a brief
confirmation message, and returns to the Ready display.
