4–6
NOTE
Before using the gauge, inspect the protective cover of
the bottom surface of the gauge’s sensor. Ensure that
the cover is in good condition, and has no deep scratches
or buildup of material. If necessary, replace the cover as
described on page A–7.
CONTINUOUS MODE
In continuous mode, the gauge takes a measurement and updates the
display every second. This mode is used for typical quality control
measurements.
Extend the telescoping handle (see Figure 1–1) to reduce the
bending required while taking measurements.
To take a measurement in continuous mode, select the mode as
described on page 2–16. Place the gauge on the test site and press
〈ENTER/START〉.
The gauge displays the measurement results, updated every second,
as shown:
##.#% Gmb(MA)
##.#% Gmm(Voidless)
D: ###.#
##.#% Voids <ESC>
NOTE
If the Temperature option (see page 2–10) is installed, the
mat temperature is also shown in the upper right corner
of the display.
Press 〈ESC〉 to return to the Ready screen.
For more information on storing measured data, see the Storing
Data section on page 5–8.
