Model 2701-B 3–9
3. ADJUSTING MEASUREMENTS
The gauge can store the mix calibration in one of four memory cells.
Use the numeric keys to store the mix calibration. Note that this will
replace any mix calibration that was previously stored in that cell.
The gauge enables the mix calibration, displays a brief confirmation
message, and returns to the Setup menu.
Slope/Intercept
The Slope/Intercept function is used to manually enter the slope
and/or intercept for a particular material. These values can be
determined using the Data Pairs function described on page 3–7, or
can be calculated manually.
To access the Slope/Intercept function, press 〈2〉 on the Entry
Method menu shown on page 3–7. The gauge prompts for the
slope and intercept values. Press 〈ENTER/START〉 after each value
is entered. After both values have been entered, the gauge displays:
Slope = #.##
Intercept = ###.#
Do you want to
accept this mix?
To return to the Setup menu without saving the mix calibration,
press the 〈NO〉 key. To save the mix calibration, press the 〈YES〉
key. The gauge requests a mix calibration ID as shown:
Mix Calib. ID
<ALPHA> for Letters
Press <ENTER>
Press the 〈ALPHA LOCK〉 key to enable the alphabetic keys on the
gauge. When the alphabetic keys are enabled, the symbol A appears
in the upper right of the display, as shown above.
