Model 2701-B 5–5
5. PROJECT DATA
ERASE PROJECTS
To erase either a selected project file or all project files, press 〈4〉 at
the Project menu shown on page 5–2. The gauge displays:
Erase:
1. One Project
2. All Projects
Press # to Select
To erase a single project, press 〈1〉. If more than one project has
been created, the gauge displays:
Prj: XXX ¦
Arrows for Scroll
<ENTER> to Select
Use the arrow keys to scroll through the project names displayed on
the first line. When the gauge displays the desired project, press
〈ENTER/START〉. At the Are you sure? prompt, press the
〈YES〉 key. The gauge erases the project and returns to the Project
menu.
To erase all projects, press 〈2〉
at the Erase menu. At the Are You
Sure? prompt, press the 〈YES〉 key. The gauge erases all the
projects and returns to the Project menu.
OUTPUT PROJECT DATA
The Output function within the Project menu allows the operator
to print (or upload) project data stored in the gauge to a printer or
computer.
To output project data, connect a serial cable to the 9-pin serial port
on the front of the gauge. Ensure that the serial cable meets the
pinout shown on page C–3. An optional serial cable, PN
106514.0002, is available from Troxler. Connect the serial cable to
the printer (or computer) serial port.
