Troxler PaveTracker Plus - MANAGING DENSITY OFFSETS

3–4
4. Subtract the measured density from the alternative density to
determine the density offset to be entered into the PaveTracker
Plus software. For example, if the density as determined by a
core analysis is 150 pcf, and the density measured by
PaveTracker Plus is 146 pcf, the density offset is +4 pcf.
NOTE
For best results, repeat the above procedure to
determine the density offset at each of several in-place
locations. Then calculate the average density offset.
MANAGING DENSITY OFFSETS
Density offsets are managed using the Density Offset menu. To
access this menu, press 〈OFFSET〉. The gauge displays:
Density Offset
#.## pcf
1-Enable 2-Disable
3-Change Offset
The gauge displays the current density offset on the second line. To
enable the offset, press 〈1〉. To disable the offset, press 〈2〉.
To enter a new density offset, press 〈3〉. The gauge prompts for the
density offset as shown below:
Density Offset
#.## pcf
Select (+/-)
