Appendix B–2
MENU MAP DESCRIPTION
Figure B–1 is a map of the menus of the PaveTracker Plus control
software and each of its submenus.
The menu map shows the function key that accesses each menu. The
map uses indentation to indicate submenus that result from selection
of a menu item. For example, the first seven lines of Figure B–1 are:
〈PROJ〉
-Project-
1. Select
2. View
3. Create
4. Erase
Erase
1. One Project
2. All Projects
This indicates that, by pressing the 〈PROJ〉 key, the operator
accesses the Project menu. The first three items under the
Project menu (1. Select, 2. View, and 3. Create)
have no submenus. The fourth item (4. Erase) does have a
submenu. Press 〈4〉 to access the Erase submenu.
NOTE
The menu map contains only the displays that allow or
require a keypad selection from multiple choices. Other
displays (such as status information, confirmation
messages, data entry screens, or error displays) are not
included.
