Model 2701-B 5–9
5. PROJECT DATA
Note that the station number, distance from centerline, and location
with respect to centerline fields are available only for continuous
mode measurements.
CONTINUOUS MODE
When taking measurements in continuous mode, the operator can
store the data in the selected project by pressing the 〈STORE〉 key
at any time when the gauge is displaying measurement data, or after
returning to the Ready screen. The gauge displays:
Do You Want To
Add Notes?
<YES> or <NO>
f Press 〈NO〉 to store only the measurement results under the
active project and return to the previous screen.
f Press 〈YES〉 to store the station number, distance from
centerline, and location with respect to centerline project notes
along with the measurement. The gauge displays:
Input Station #
Press <ENTER>
Enter the station number (up to eight characters) and press
〈ENTER/START〉. The gauge displays:
Station Distance
From Center Line?
#.# ft
Press <ENTER>
