10
Section A
Setting Up Your Treadmill
Treadmill Assembly
Pedestal Positioning (Continued)
5. Insert 2 screws (3/8”-16 X 4”)
and lock washers on each side
of the Pedestal. Tighten all
4 screws with the Allen
Wrench provided.
Use the 2 screws removed from
the Lower Pedestal Spacer and the
2 screws and 4 washers from the
hardware package. When inserting and
tightening screws, make sure that they go in straight, through the holes in the
Pedestal and thread into the threaded portion of the base.
NOTE:
Do not operate unless all 4 screws are securely tightened to
insure that they do not work themselves loose.
6. Tighten the Pedestal Hinge Screws with the Allen wrench
provided.
Handrail Assembly
7. Remove the protective plastic caps from handrail sleeves.
8. Assemble both handrails over the handrail sleeves.
NOTE:
The left handrail has a sticker marked “L”. The right handrail
does not have a sticker.
Continued on Next Page
