Parameterizing and Configuring
Configuring the devices at EtherNet/IP
112
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Common services
Service code Class Instance Service name
Dec. Hex.
1 0x01 Yes Yes Get_Attribute_All
Returns a predefined list of object attributes.
14 0x0E Yes Yes Get_Attribute_Single
Returns the content of a specified attribute.
Configuration Assembly (Instance 106)
The modules support Configuration Assembly.
The Configuration Assembly contains:
10 bytes module configuration data (EtherNet/IP specific)
+ x Byte (parameter data, depending on device type)
Device Configuration Data
The default values are written in bold.
Designation Value Meaning
QuickConnect 0
disabled
QuickConnect is deactivated.
1 Activated QuickConnect is activated.
Eth x Port-Setup 0
Auto negotiation
The port is set to autonegotiation.
1 100BT/FD Defined setting of communication paramet-
ers for the Ethernet port to:
n 100BaseT
n Full duplex
