V04.00 | 2021/05
113
n Configuration Assembly – TBEN-S1-8DIP/TBEN-S1-8DIP-D
Byte no. Bit no.
Dec. Hex. 7 6 5 4 3 2 1 0
Device Configuration Data [}112]
0…9 0x00…
0x09
- Eth2 Port-
Setup
Eth1 Port-
Setup
Quick
Connect
Parameter data [}39]
Channel 0
10 0x0A DMOD_CNT DI0
11 0x0B - - - - - - - DIFT DI0
12 0x0C IST DI0
13 0x0D -
Channel 1
14 0x0E DMOD DI1
15 0x0F - - - - - - - DIFT DI1
16 0x10 IST DI1
17 0x11 -
Channel 2
18 0x12 Assignment similar to channel 1 (byte 14…17)
19 0x13
20 0x14
21 0x15
…
Channel 7
38 0x26 Assignment similar to channel 1 (byte 14…17)
39 0x27
40 0x28
41 0x29
