turck TBEN-S Series User Manual

Parameterizing and Configuring
Configuring the devices at EtherNet/IP
116
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
n Configuration Assembly – TBEN-S1-4DXP
Byte no. Bit no.
Dec. Hex. 7 6 5 4 3 2 1 0
Device Configuration Data [}112]
0…9 0x00…
0x09
- Eth2 Port-
Setup
Eth1 Port-
Setup
QuickCon-
nect
Parameter data [}39]
10 0x0A - - - - SRO3 SRO2 SRO1 SRO0
11 0x0B - - - - EN DO3 EN DO2 EN DO1 EN DO0
12 0x0C DMOD_CNT DX0
13 0x0D - - - - - - - DIFT DX0
14 0x0E IST DX0
15 0x0F -
16 0x10 DMOD_DX1
17 0x11 - - - - - - - DIFT DX1
18 0x12 IST DX1
19 0x13 -
20 0x14 DMOD_DX2
21 0x15 - - - - - - - DIFT DX2
22 0x16 IST DI2
23 0x17 -
24 0x18 DMOD_DX3
25 0x19 - - - - - - - DIFT DX3
26 0x1A IST DX3
27 0x1B -
