n Output data – TBEN-S1-4DIP-4DOP [}53]
control word + 4 words
Word no. Bit no.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Control
0x0000
OUT
- - - - - - - - - - - - - - - -
0x0001 - - - - - - - - - - - - DO7
C7P4
DO6
C6P4
DO5
C5P4
DO4
C4P4
Latch
reset
0x0002 - - - - - - - - - - - - DI3 DI2 DI1 DI0
CNT-
reset
0x0003 - - - - - - - - - - - - - - - CNT
reset
PWM Ch7
0x0004 - - - - - - - - Duty Cycle
