turck TBEN-S Series User Manual

V04.00 | 2021/05
183
2…10 V Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. Value × 2.441 × 10
-4
) V + 2 V
> 10.1000 V "Upper limit value exceeded” ON 32767 7FFF
< 10.0500 V "Upper limit value exceeded" OFF 32767 7FFF
10.0000 V Nominal range 32767 7FFF
9.999 V 32766 7FFE
9.992 V 32736 7FE0
2.0004 V 16 0010
2.0 V 0 0000
> 1.95 V "Lower limit value underrun" OFF 0 0000
< 1.90 V "Lower limit value underrun" ON 0 0000
> 1.5 V "Wire break" OFF 0 0000
< 1.45 V "Wire break" ON 0 0000
0…5 V Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. value × 1.526 × 10
-4
) V
> 5.1000 V "Upper limit value exceeded” ON 32767 7FFF
< 5.0500 V "Upper limit value exceeded" OFF 32767 7FFF
5.0000 V Nominal range 32767 7FFF
4.999 V 32766 7FFE
4.995 V 32736 7FE0
0.002 V 16 0010
0 V 0 0000
> -0.05 V "Lower limit value underrun" OFF 0 0000
< -0.10 V "Lower limit value underrun" ON 0 0000
1…5 V Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. Value × 1.2207 × 10
-4
) V + 1 V
> 5.1000 V "Upper limit value exceeded” ON 32767 7FFF
< 5.0500 V "Upper limit value exceeded" OFF 32767 7FFF
5.0000 V Nominal range 32767 7FFF
4.999 V 32766 7FFE
4.996 V 32736 7FE0
1.002 V 16 0010
1.000 V 0 0000
> 0.95 V "Lower limit value underrun" OFF 0 0000
< 0.90 V "Lower limit value underrun" ON 0 0000
> 0.75 V "Wire break" OFF 0 0000
< 0.70 V "Wire break" ON 0 0000
