Measurement value representation of analog modules
184
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
-1…1 V Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. value × 3.05185 × 10
-5
) V
> 1.0100 V "Upper limit value exceeded” ON 32767 7FFF
< 1.0050 V "Upper limit value exceeded" OFF 32767 7FFF
1.0000 V Nominal range 32767 7FFF
0.999 V 32766 7FFE
0.996 V 32736 7FE0
0 V 16 0010
0 V 1 0001
0 V 0 0000
0 V -1 FFFF
0 V -16 FFF0
-0.909 V -32752 8010
-0.999 V -32767 8001
-1.000 V -32768 8000
> -1.0050 V "Lower limit value underrun" OFF -32768 8000
< -1.0100 V "Lower limit value underrun" ON -32768 8000
-500…500 mV Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. value × 1.5259 × 10
-2
) mV
> 505.0 mV "Upper limit value exceeded” ON 32767 7FFF
< 502.5 mV "Upper limit value exceeded" OFF 32767 7FFF
500.000 mV Nominal range 32767 7FFF
499.95 mV 32766 7FFE
499.527 mV 32736 7FE0
244.244 mV 16 0010
0.015 mV 1 0001
0 mV 0 0000
-0.015 mV -1 FFFF
-244.244 mV -16 FFF0
-499.771 mV -32752 8010
-499.999 mV -32767 8001
-500.000 mV -32768 8000
> -502.5 mV "Lower limit value underrun" OFF -32768 8000
< -505.0 mV "Lower limit value underrun" ON -32768 8000
