turck TBEN-S Series User Manual

V04.00 | 2021/05
185
-100…100 mV Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. value × 3.0519 × 10
-3
) V
> 101.000 mV "Upper limit value exceeded” ON 32767 7FFF
< 100.500 mV "Upper limit value exceeded" OFF 32767 7FFF
100.00 mV Nominal range 32767 7FFF
99.999 mV 32766 7FFE
99.905 mV 32736 7FE0
0.049 mV 16 0010
0.003 mV 1 0001
0 mV 0 0000
-0.003 mV -1 FFFF
-0.049 mV -16 FFF0
-99.954 mV -32752 8010
-99.999 mV -32767 8001
-100.000 mV -32768 8000
> -100.500 mV "Lower limit value underrun" OFF -32768 8000
< -101.000 mV "Lower limit value underrun" ON -32768 8000
-50…50 mV Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. value × 1.526 × 10
-3
) V
> 50.50 mV "Upper limit value exceeded” ON 32767 7FFF
< 50.30 mV "Upper limit value exceeded" OFF 32767 7FFF
50.00 mV Nominal range 32767 7FFF
49.999 mV 32766 7FFE
49.953 mV 32736 7FE0
0.024 mV 16 0010
0.002 mV 1 0001
0 mV 0 0000
-0.002 mV -1 FFFF
-0.024 mV -16 FFF0
-49.977 mV -32752 8010
-49.997 mV -32767 8001
-50.000 mV -32768 8000
> -50.30 mV "Lower limit value underrun" OFF -32768 8000
< -50.50 mV "Lower limit value underrun" ON -32768 8000
