turck TBEN-S Series User Manual

Operating
Measurement value representation of analog modules
186
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Voltage – extended range
-10…10 V Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. value × 3.617 × 10
-4
) V
> 11.76 V "Upper limit value exceeded” ON > 35513 > 7F01
< 11.60 V "Upper limit value exceeded" OFF > 32071 < 7D47
11.851 V Nominal range 32767 7FFF
11.759 V 32512 7F00
10 V 27648 6C00
5.926 V 16384 4000
0 V 0 0000
-1.76 V -4865 ECFF
-2.500 V -6912 E500
-5.926 V -16384 C000
-10 V -27648 9400
-11.759 V -32512 8100
-11.851 V -37768 8000
> -11.60 V "Lower limit value underrun" OFF > -32071 > 82B9
> -11.76 V "Lower limit value underrun" ON > -35513 < 80FF
0…10 V Diagnostics decimal hexadecimal
(two's complement)
Voltage value U
M
= (dec. value × 3.617 × 10
-4
) V
> 11.76 V "Upper limit value exceeded” ON > 32513 > 7F01
< 11.60 V "Upper limit value exceeded" OFF > 32071 < 7D47
11.851 V Nominal range 32767 7FFF
11.759 V 32512 7F00
10 V 27648 6C00
5.926 V 16384 4000
0 V 0 0000
> -0.05 V "Lower limit value underrun" OFF > -138 > FF76
< -0.10 V "Lower limit value underrun" ON > -276 < FEEC
