Voltage – NE43
Decimal hexadecimal
(two's complement)
-10…10 V
Dec. value = 2764.8 (1/V) × U
out
(V)
32767 7FFF 11.00 V
11001 2AF9 11.000 V
11000 2AF8 11.000 V
10501 2905 10.501 V
10500 2904 10.500 V
10001 2711 10.001 V
10000 2710 Nominal range 10.000 V
4000 0FA0 4.000 V
1 0001 0.001 V
0 0000 0.000 V
-1 FFFF -0.001 V
-4000 F060 -4.000 V
-10000 D8F0 -10.000 V
-10001 D8EF -10.001 V
-10500 D6FC -10.500 V
-10501 D6FB -10.501 V
-11000 D508 -11.000 V
-11001 D507 -11.000 V
-32768 8000 -11.000 V
Decimal hexadecimal
(two's complement)
0…10 V
Dec. value = 1000 (1/V) × U
out
(V)
65535 7FFF 11.000 V
11001 2AF9 11.000 V
11000 2AF8 11.000 V
10501 2905 10.501 V
10500 2904 10.500 V
10001 2711 10.001 V
10000 2710 Nominal range 10.000 V
4000 0FA0 4.000 V
2000 07D0 2.000 V
1 0001 0.001 V
0 0000 0 V
