turck TBEN-S Series User Manual

Operating
Measurement value representation of analog modules
212
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
Decimal hexadecimal
(two's complement)
0…5 V
Dec. value = 1000 (1/V) × U
out
(V)
65535 7FFF 5.500 V
5501 157D 5.500 V
5500 157C 5.500 V
5000 1388 Nominal range 5.000 V
4000 0FA0 4.000 V
2000 07D0 2.000 V
1 0001 0.001 V
0 0000 0 V
Decimal hexadecimal
(two's complement)
0…5 V
Dec. value = 1000 (1/V) × U
out
(V)
65535 7FFF 11.000 V
11001 2AF9 11.000 V
11000 2AF8 11.000 V
10000 2710 Nominal range 10.000 V
4000 0FA0 4.000 V
2000 07D0 2.000 V
1 0001 0.001 V
0 0000 0 V
Decimal hexadecimal
(two's complement)
1…5 V
Dec. value = 1000 (1/V) × U
out
(V)
65535 7FFF 5.500 V
5501 157D 5.500 V
5500 157C 5.500 V
5000 1388 Nominal range 5.000 V
4000 0FA0 4.000 V
2000 07D0 2.000 V
1 0001 0.001 V
0 0000 0 V
